In this article, I will explain you how to create admin grid and form without ui component. In Magento 2, You can create admin grid and form using ui component method and block method (layout method or without ui component). There are some modules also in Magento 2 core which admin grid and form without ui component.
Magento 2 grid is a one type of table which listing collection of your database table and provides functionality of sorting, mass delete, update etc.
In Magento 2, UI Components are little bit complex structure to develop UI Grid and Form. So, sometimes people prefer to use block methods to develop form and grid in their module.
You may also like this :
- Magento 2 : Create UI Component Grid and Form
- Add new page layout option in Magento 2
- Magento 2 Get Config Value in Layout XML
So, Let’s start to create admin grid and form without ui component.
To create admin grid and form :
1) First of all, For register your module, create registration.php file at app/code/Rh/Blog/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
use \Magento\Framework\Component\ComponentRegistrar;
ComponentRegistrar::register(ComponentRegistrar::MODULE, 'Rh_Blog', __DIR__);
2) After that, For define your module, create module.xml file at app/code/Rh/Blog/etc/ and paste the below code :
<?xml version="1.0"?>
<!--
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*
* Created By : Rohan Hapani
*/
-->
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:Module/etc/module.xsd">
<module name="Rh_Blog" schema_version="1.0.0" setup_version="1.0.0"/>
</config>
3) After that, For create database, create InstallSchema.php file at app/code/Rh/Blog/Setup/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Setup;
use Magento\Framework\DB\Ddl\Table;
use Magento\Framework\Setup\InstallSchemaInterface;
use Magento\Framework\Setup\ModuleContextInterface;
use Magento\Framework\Setup\SchemaSetupInterface;
/**
* @codeCoverageIgnore
*/
class InstallSchema implements InstallSchemaInterface
{
/**
* {@inheritdoc}
* @SuppressWarnings(PHPMD.ExcessiveMethodLength)
*/
public function install(SchemaSetupInterface $setup, ModuleContextInterface $context)
{
$installer = $setup;
$installer->startSetup();
/**
* Create table 'rh_blog'
*/
if (!$installer->tableExists('rh_blog')) {
$table = $installer->getConnection()->newTable(
$installer->getTable('rh_blog')
)->addColumn(
'id',
Table::TYPE_INTEGER,
null,
[
'identity' => true,
'nullable' => false,
'primary' => true,
'unsigned' => true,
],
'ID'
)->addColumn(
'name',
Table::TYPE_TEXT,
255,
[
'nullable => false',
],
'Name'
)->addColumn(
'title',
Table::TYPE_TEXT,
'255',
[
'nullable => false',
],
'Blog Title'
)->addColumn(
'content',
Table::TYPE_TEXT,
'2M',
[],
'Blog Content'
)->addColumn(
'status',
Table::TYPE_SMALLINT,
null,
[
'nullable' => false,
],
'Status'
)->addColumn(
'created_at',
Table::TYPE_TIMESTAMP,
null,
[
'nullable' => false,
'default' => Table::TIMESTAMP_INIT,
],
'Created At'
)->setComment('Blog Table');
$installer->getConnection()->createTable($table);
}
$installer->endSetup();
}
}
Model Folder
4) Then, For handle business logic and single instance of object, create Blog.php model file at app/code/Rh/Blog/Model/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Model;
class Blog extends \Magento\Framework\Model\AbstractModel
{
protected function _construct()
{
$this->_init('Rh\Blog\Model\ResourceModel\Blog');
}
}
5) After that, For data mapping of storage structure, create Blog.php resource model file at app/code/Rh/Blog/Model/ResourceModel/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Model\ResourceModel;
use Magento\Framework\Model\ResourceModel\Db\AbstractDb;
class Blog extends AbstractDb
{
/**
* Initialize resource model
*
* @return void
*/
protected function _construct()
{
$this->_init('rh_blog', 'id');
}
}
6) After that, For set model and resourcemodel file and manage collection, create Collection.php file at app/code/Rh/Blog/Model/ResourceModel/Blog/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Model\ResourceModel\Blog;
use Magento\Framework\Model\ResourceModel\Db\Collection\AbstractCollection;
class Collection extends AbstractCollection
{
protected function _construct()
{
$this->_init('Rh\Blog\Model\Blog', 'Rh\Blog\Model\ResourceModel\Blog');
}
}
7) After that, For status enable disable option, create Status.php optionArray file at app/code/Rh/Blog/Model/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Model;
class Status implements \Magento\Framework\Option\ArrayInterface
{
const STATUS_ENABLED = 1;
const STATUS_DISABLED = 2;
public function toOptionArray()
{
return [
[
self::STATUS_ENABLED => __('Enabled'),
self::STATUS_DISABLED => __('Disabled'),
],
];
}
public static function getOptionArray()
{
return [
self::STATUS_ENABLED => __('Enabled'),
self::STATUS_DISABLED => __('Disabled'),
];
}
}
etc folder
8) Then, For add admin router of module, create routes.xml file at app/code/Rh/Blog/etc/adminhtml/ and paste the below code :
<?xml version="1.0"?>
<!--
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*
* Created By : Rohan Hapani
*/
-->
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="../../../../../../lib/internal/Magento/Framework/App/etc/routes.xsd">
<router id="admin">
<route id="blog" frontName="blog">
<module name="Rh_Blog" before="Magento_Adminhtml" />
</route>
</router>
</config>
9) After that, For add link in admin menu, create menu.xml file at app/code/Rh/Blog/etc/adminhtml/ and paste the below code :
<?xml version="1.0"?>
<!--
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*
* Created By : Rohan Hapani
*/
-->
<config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="../../../../Magento/Backend/etc/menu.xsd">
<menu>
<add id="Rh_Blog::view" title="RH Blog" module="Rh_Blog" sortOrder="10" resource="Rh_Blog::view"/>
<add id="Rh_Blog::grid" title="Manage Blog Records" module="Rh_Blog" sortOrder="9" parent="Rh_Blog::view" action="blog/grid/index" resource="Rh_Blog::view"/>
</menu>
</config>
Block Folder
10) Then, For backend grid container block, Create Grid.php file at app/code/Rh/Blog/Block/Adminhtml/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml;
/**
* Backend grid container block
*/
class Grid extends \Magento\Backend\Block\Widget\Container
{
/**
* @var string
*/
protected $_template = 'grid/view.phtml';
/**
* @param \Magento\Backend\Block\Widget\Context $context
* @param array $data
*/
public function __construct(
\Magento\Backend\Block\Widget\Context $context,
array $data = []
) {
parent::__construct($context, $data);
}
/**
* {@inheritdoc}
*/
protected function _prepareLayout()
{
$addButtonProps = [
'id' => 'add_new_grid',
'label' => __('Add New'),
'class' => 'add',
'button_class' => '',
'class_name' => 'Magento\Backend\Block\Widget\Button\SplitButton',
'options' => $this->_getAddButtonOptions(),
];
$this->buttonList->add('add_new', $addButtonProps);
$this->setChild('grid', $this->getLayout()->createBlock('Rh\Blog\Block\Adminhtml\Grid\Grid', 'grid.view.grid'));
return parent::_prepareLayout();
}
/**
* @return array
*/
protected function _getAddButtonOptions()
{
$splitButtonOptions[] = [
'label' => __('Add New'),
'onclick' => "setLocation('" . $this->_getCreateUrl() . "')",
];
return $splitButtonOptions;
}
/**
* @return string
*/
protected function _getCreateUrl()
{
return $this->getUrl('blog/*/new');
}
/**
* @return string
*/
public function getGridHtml()
{
return $this->getChildHtml('grid');
}
}
11) After that, For add column in grid, create Grid.php file at app/code/Rh/Blog/Block/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml\Grid;
class Grid extends \Magento\Backend\Block\Widget\Grid\Extended
{
/**
* @var \Rh\Blog\Model\Status
*/
protected $_status;
/**
* @var \Rh\Blog\Model\BlogFactory
*/
protected $_blogFactory;
/**
* @var \Magento\Framework\Module\Manager
*/
protected $moduleManager;
/**
* @param \Magento\Backend\Block\Template\Context $context
* @param \Magento\Backend\Helper\Data $backendHelper
* @param \Rh\Blog\Model\BlogFactory $blogFactory
* @param \Rh\Blog\Model\Status $status
* @param \Magento\Framework\Module\Manager $moduleManager
* @param array $data
*/
public function __construct(
\Magento\Backend\Block\Template\Context $context,
\Magento\Backend\Helper\Data $backendHelper,
\Rh\Blog\Model\BlogFactory $blogFactory,
\Rh\Blog\Model\Status $status,
\Magento\Framework\Module\Manager $moduleManager,
array $data = []
) {
$this->_blogFactory = $blogFactory;
$this->_status = $status;
$this->moduleManager = $moduleManager;
parent::__construct($context, $backendHelper, $data);
}
/**
* @return void
*/
protected function _construct()
{
parent::_construct();
$this->setId('gridGrid');
$this->setDefaultSort('id');
$this->setDefaultDir('DESC');
$this->setSaveParametersInSession(true);
$this->setUseAjax(true);
$this->setVarNameFilter('grid_record');
}
/**
* @return $this
*/
protected function _prepareCollection()
{
$collection = $this->_blogFactory->create()->getCollection();
$this->setCollection($collection);
parent::_prepareCollection();
return $this;
}
/**
* @return $this
*/
protected function _prepareColumns()
{
$this->addColumn(
'id',
[
'header' => __('ID'),
'type' => 'number',
'index' => 'id',
'header_css_class' => 'col-id',
'column_css_class' => 'col-id',
]
);
$this->addColumn(
'name',
[
'header' => __('Name'),
'index' => 'name',
]
);
$this->addColumn(
'title',
[
'header' => __('Title'),
'index' => 'title',
]
);
$this->addColumn(
'status',
[
'header' => __('Status'),
'index' => 'status',
'type' => 'options',
'options' => $this->_status->getOptionArray(),
]
);
$this->addColumn(
'created_at',
[
'header' => __('Created At'),
'index' => 'created_at',
]
);
$this->addColumn(
'edit',
[
'header' => __('Edit'),
'type' => 'action',
'getter' => 'getId',
'actions' => [
[
'caption' => __('Edit'),
'url' => [
'base' => 'blog/*/edit',
],
'field' => 'id',
],
],
'filter' => false,
'sortable' => false,
'index' => 'stores',
'header_css_class' => 'col-action',
'column_css_class' => 'col-action',
]
);
$this->addColumn(
'delete',
[
'header' => __('Delete'),
'type' => 'action',
'getter' => 'getId',
'actions' => [
[
'caption' => __('Delete'),
'url' => [
'base' => 'blog/*/delete',
],
'field' => 'id',
],
],
'filter' => false,
'sortable' => false,
'index' => 'stores',
'header_css_class' => 'col-action',
'column_css_class' => 'col-action',
]
);
$block = $this->getLayout()->getBlock('grid.bottom.links');
if ($block) {
$this->setChild('grid.bottom.links', $block);
}
return parent::_prepareColumns();
}
/**
* @return $this
*/
protected function _prepareMassaction()
{
$this->setMassactionIdField('id');
$this->getMassactionBlock()->setFormFieldName('id');
$this->getMassactionBlock()->addItem(
'delete',
[
'label' => __('Delete'),
'url' => $this->getUrl('blog/*/massDelete'),
'confirm' => __('Are you sure?'),
]
);
$statuses = $this->_status->toOptionArray();
array_unshift($statuses, ['label' => '', 'value' => '']);
$this->getMassactionBlock()->addItem(
'status',
[
'label' => __('Change status'),
'url' => $this->getUrl('blog/*/massStatus', ['_current' => true]),
'additional' => [
'visibility' => [
'name' => 'status',
'type' => 'select',
'class' => 'required-entry',
'label' => __('Status'),
'values' => $statuses,
],
],
]
);
return $this;
}
/**
* @return string
*/
public function getGridUrl()
{
return $this->getUrl('blog/*/grid', ['_current' => true]);
}
/**
* @return string
*/
public function getRowUrl($row)
{
return $this->getUrl('blog/*/edit', ['id' => $row->getId()]);
}
}
12) After that, For create block edit page layout and add buttons, Create Edit.php file at app/code/Rh/Blog/Block/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml\Grid;
/**
* Block for edit page
*/
class Edit extends \Magento\Backend\Block\Widget\Form\Container
{
/**
* @var \Magento\Framework\Registry
*/
protected $_coreRegistry = null;
/**
* @param \Magento\Backend\Block\Widget\Context $context
* @param \Magento\Framework\Registry $registry
* @param array $data
*/
public function __construct(
\Magento\Backend\Block\Widget\Context $context,
\Magento\Framework\Registry $registry,
array $data = []
) {
$this->_coreRegistry = $registry;
parent::__construct($context, $data);
}
/**
* Init container
* @return void
*/
protected function _construct()
{
$this->_objectId = 'id';
$this->_blockGroup = 'rh_blog';
$this->_controller = 'adminhtml_grid';
parent::_construct();
$this->buttonList->update('save', 'label', __('Save Grid'));
$this->buttonList->add(
'saveandcontinue',
[
'label' => __('Save and Continue Edit'),
'class' => 'save',
'data_attribute' => [
'mage-init' => [
'button' => ['event' => 'saveAndContinueEdit', 'target' => '#edit_form'],
],
],
],
-100
);
$this->buttonList->update('delete', 'label', __('Delete'));
}
/**
* Get edit form container header text
*
* @return \Magento\Framework\Phrase|string
*/
public function getHeaderText()
{
if ($this->_coreRegistry->registry('rh_blog_form_data')->getId()) {
return __("Edit Post '%1'", $this->escapeHtml($this->_coreRegistry->registry('rh_blog_form_data')->getTitle()));
} else {
return __('New Record');
}
}
/**
* Retrieve the save and continue edit Url
*
* @return string
*/
protected function _getSaveAndContinueUrl()
{
return $this->getUrl('blog/*/save', ['_current' => true, 'back' => 'edit', 'active_tab' => '{{tab_id}}']);
}
/**
* Prepare the layout.
*
* @return $this
*/
protected function _prepareLayout()
{
$this->_formScripts[] = "
function toggleEditor() {
if (tinyMCE.getInstanceById('page_content') == null) {
tinyMCE.execCommand('mceAddControl', false, 'content');
} else {
tinyMCE.execCommand('mceRemoveControl', false, 'content');
}
};
";
return parent::_prepareLayout();
}
}
13) Then, For create form object and set values in form, Create Form.php file at app/code/Rh/Blog/Block/Adminhtml/Grid/Edit/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml\Grid\Edit;
/**
* Adminhtml block grid edit form block
*/
class Form extends \Magento\Backend\Block\Widget\Form\Generic
{
/**
* Prepare the form.
*
* @return $this
*/
protected function _prepareForm()
{
/** @var \Magento\Framework\Data\Form $form */
$form = $this->_formFactory->create(
[
'data' => [
'id' => 'edit_form',
'action' => $this->getData('action'),
'method' => 'post',
'enctype' => 'multipart/form-data',
],
]
);
$form->setUseContainer(true);
$this->setForm($form);
return parent::_prepareForm();
}
}
14) After that, For create form tab left menu, create Tabs.php file at app/code/Rh/Blog/Block/Admimhtml/Grid/Edit/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml\Grid\Edit;
/**
* Admin blog left menu
*/
class Tabs extends \Magento\Backend\Block\Widget\Tabs
{
/**
* @return void
*/
protected function _construct()
{
parent::_construct();
$this->setId('grid_record');
$this->setDestElementId('edit_form');
$this->setTitle(__('Blog Information'));
}
}
15) Further, For create tabs form elements, create Main.php file at app/code/Rh/Blog/Block/Adminhtml/Grid/Edit/Tab/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Block\Adminhtml\Grid\Edit\Tab;
use Magento\Backend\Block\Widget\Form\Generic;
use Magento\Backend\Block\Widget\Tab\TabInterface;
/**
* Blog form block
*/
class Main extends Generic implements TabInterface
{
/**
* Core registry
*
* @var \Magento\Framework\Registry
*/
protected $_coreRegistry = null;
/**
* @var \Magento\Backend\Model\Auth\Session
*/
protected $_adminSession;
/**
* @var \Rh\Blog\Model\Status
*/
protected $_status;
/**
* @param \Magento\Backend\Block\Template\Context $context
* @param \Magento\Framework\Registry $registry
* @param \Magento\Framework\Data\FormFactory $formFactory
* @param \Magento\Backend\Model\Auth\Session $adminSession
* @param \Rh\Blog\Model\Status $status
* @param array $data
*/
public function __construct(
\Magento\Backend\Block\Template\Context $context,
\Magento\Framework\Registry $registry,
\Magento\Framework\Data\FormFactory $formFactory,
\Magento\Backend\Model\Auth\Session $adminSession,
\Rh\Blog\Model\Status $status,
array $data = []
) {
$this->_adminSession = $adminSession;
$this->_status = $status;
parent::__construct($context, $registry, $formFactory, $data);
}
/**
* Prepare the form.
*
* @return $this
*/
protected function _prepareForm()
{
$model = $this->_coreRegistry->registry('rh_blog_form_data');
$isElementDisabled = false;
$form = $this->_formFactory->create();
$form->setHtmlIdPrefix('page_');
$fieldset = $form->addFieldset('base_fieldset', ['legend' => __('Blog Information')]);
if ($model->getId()) {
$fieldset->addField('id', 'hidden', ['name' => 'id']);
}
$fieldset->addField(
'name',
'text',
[
'name' => 'name',
'label' => __('Name'),
'title' => __('Name'),
'required' => true,
'value' => $this->_adminSession->getUser()->getFirstname(),
'disabled' => $isElementDisabled,
]
);
$fieldset->addField(
'title',
'text',
[
'name' => 'title',
'label' => __('Blog Title'),
'title' => __('Blog Title'),
'required' => true,
'disabled' => $isElementDisabled,
]
);
$contentField = $fieldset->addField(
'content',
'textarea',
[
'name' => 'content',
'label' => __('Content'),
'title' => __('Content'),
'required' => true,
'disabled' => $isElementDisabled,
]
);
$dateFormat = $this->_localeDate->getDateFormat(\IntlDateFormatter::SHORT);
$fieldset->addField(
'status',
'select',
[
'label' => __('Status'),
'title' => __('Status'),
'name' => 'status',
'required' => true,
'options' => $this->_status->getOptionArray(),
'disabled' => $isElementDisabled,
]
);
if (!$model->getId()) {
$model->setData('status', $isElementDisabled ? '0' : '1');
}
$form->addValues($model->getData());
$this->setForm($form);
return parent::_prepareForm();
}
/**
* Return Tab label
*
* @return \Magento\Framework\Phrase
*/
public function getTabLabel()
{
return __('Blog Information');
}
/**
* Return Tab title
*
* @return \Magento\Framework\Phrase
*/
public function getTabTitle()
{
return __('Blog Information');
}
/**
* Can show tab in tabs
*
* @return boolean
*/
public function canShowTab()
{
return true;
}
/**
* Tab is hidden
*
* @return boolean
*/
public function isHidden()
{
return false;
}
/**
* Check permission for passed action
*
* @param string $resourceId
* @return bool
*/
protected function _isAllowedAction($resourceId)
{
return $this->_authorization->isAllowed($resourceId);
}
}
Controller Folder
16) After that, For action file for grid page, create Index.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action;
use Magento\Backend\App\Action\Context;
use Magento\Framework\View\Result\PageFactory;
/**
* Main page controller
*/
class Index extends Action
{
/**
* @var PageFactory
*/
protected $resultPageFactory;
/**
* @param Context $context
* @param PageFactory $resultPageFactory
*/
public function __construct(
Context $context,
PageFactory $resultPageFactory
) {
parent::__construct($context);
$this->resultPageFactory = $resultPageFactory;
}
/**
* @return \Magento\Framework\View\Result\PageFactory
*/
public function execute()
{
$resultPage = $this->resultPageFactory->create();
$resultPage->setActiveMenu('RH_Blog::grid');
$resultPage->addBreadcrumb(__('Manage Grid View'), __('Manage Grid View'));
$resultPage->getConfig()->getTitle()->prepend(__('Manage Blog'));
return $resultPage;
}
}
17) Further, For set html content of grid columns, Create Grid.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action;
use Magento\Backend\App\Action\Context;
use Magento\Framework\Controller\Result\RawFactory;
use Magento\Framework\View\LayoutFactory;
/**
* Grid Controller
*/
class Grid extends Action
{
/**
* @var Rawfactory
*/
protected $resultRawFactory;
/**
* @var LayoutFactory
*/
protected $layoutFactory;
/**
* @param Context $context
* @param Rawfactory $resultRawFactory
* @param LayoutFactory $layoutFactory
*/
public function __construct(
Context $context,
Rawfactory $resultRawFactory,
LayoutFactory $layoutFactory
) {
parent::__construct($context);
$this->resultRawFactory = $resultRawFactory;
$this->layoutFactory = $layoutFactory;
}
/**
* @return \Magento\Framework\Controller\Result\RawFactory
*/
public function execute()
{
$resultRaw = $this->resultRawFactory->create();
$blogHtml = $this->layoutFactory->create()->createBlock(
'Rh\Blog\Block\Adminhtml\Grid\Grid',
'grid.view.grid'
)->toHtml();
return $resultRaw->setContents($blogHtml);
}
}
18) After that, For new record action, create NewAction.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
/**
* New Record Form Controller
*/
class NewAction extends \Magento\Backend\App\Action
{
/**
* @var \Magento\Backend\Model\View\Result\ForwardFactory
*/
protected $resultForwardFactory;
/**
* @param \Magento\Backend\App\Action\Context $context
* @param \Magento\Backend\Model\View\Result\ForwardFactory $resultForwardFactory
*/
public function __construct(
\Magento\Backend\App\Action\Context $context,
\Magento\Backend\Model\View\Result\ForwardFactory $resultForwardFactory
) {
$this->resultForwardFactory = $resultForwardFactory;
parent::__construct($context);
}
/**
* Create new blog record page
*
* @return \Magento\Backend\Model\View\Result\ForwardFactory
*/
public function execute()
{
$resultForward = $this->resultForwardFactory->create();
return $resultForward->forward('edit');
}
/**
* @return boolean
*/
protected function _isAllowed()
{
return true;
}
}
19) Then, For edit form action, create Edit.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action;
use Magento\Framework\Controller\ResultFactory;
/**
* Edit form controller
*/
class Edit extends \Magento\Backend\App\Action
{
/**
* Core registry
*
* @var \Magento\Framework\Registry
*/
protected $_coreRegistry = null;
/**
* @var \Magento\Backend\Model\Session
*/
protected $adminSession;
/**
* @var \Rh\Blog\Model\BlogFactory
*/
protected $blogFactory;
/**
* @param Action\Context $context
* @param \Magento\Framework\Registry $registry
* @param \Magento\Backend\Model\Session $adminSession
* @param \Rh\Blog\Model\BlogFactory $blogFactory
*/
public function __construct(
Action\Context $context,
\Magento\Framework\Registry $registry,
\Magento\Backend\Model\Session $adminSession,
\Rh\Blog\Model\BlogFactory $blogFactory
) {
$this->_coreRegistry = $registry;
$this->adminSession = $adminSession;
$this->blogFactory = $blogFactory;
parent::__construct($context);
}
/**
* @return boolean
*/
protected function _isAllowed()
{
return true;
}
/**
* Add blog breadcrumbs
*
* @return $this
*/
protected function _initAction()
{
/** @var \Magento\Backend\Model\View\Result\Page $resultPage */
$resultPage = $this->resultFactory->create(ResultFactory::TYPE_PAGE);
$resultPage->setActiveMenu('RH_Blog::grid')->addBreadcrumb(__('Blog'), __('Blog'))->addBreadcrumb(__('Manage Blog'), __('Manage Blog'));
return $resultPage;
}
/**
* @return \Magento\Backend\Model\View\Result\Page
*/
public function execute()
{
$id = $this->getRequest()->getParam('id');
$model = $this->blogFactory->create();
if ($id) {
$model->load($id);
if (!$model->getId()) {
$this->messageManager->addError(__('This blog record no longer exists.'));
$resultRedirect = $this->resultRedirectFactory->create();
return $resultRedirect->setPath('*/*/');
}
}
$data = $this->adminSession->getFormData(true);
if (!empty($data)) {
$model->setData($data);
}
$this->_coreRegistry->register('rh_blog_form_data', $model);
$resultPage = $this->_initAction();
$resultPage->addBreadcrumb($id ? __('Edit Post') : __('New Blog'), $id ? __('Edit Post') : __('New Blog'));
$resultPage->getConfig()->getTitle()->prepend(__('Grids'));
$resultPage->getConfig()->getTitle()->prepend($model->getId() ? $model->getTitle() : __('New Blog'));
return $resultPage;
}
}
20) Further, For delete record action, Create Delete.php file at app/code/Rh/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action;
use Magento\Backend\App\Action\Context;
/**
* Delete Controller
*/
class Delete extends \Magento\Backend\App\Action
{
/**
* @var \Rh\Blog\Model\BlogFactory
*/
protected $blogFactory;
/**
* @param Context $context
* @param \Rh\Blog\Model\BlogFactory $blogFactory
*/
public function __construct(
Context $context,
\Rh\Blog\Model\BlogFactory $blogFactory
) {
parent::__construct($context);
$this->blogFactory = $blogFactory;
}
/**
* @return bool
*/
protected function _isAllowed()
{
return $this->_authorization->isAllowed('RH_Blog::view');
}
/**
* @return \Magento\Backend\Model\View\Result\Redirect
*/
public function execute()
{
$id = $this->getRequest()->getParam('id');
$resultRedirect = $this->resultRedirectFactory->create();
if ($id) {
try {
$model = $this->blogFactory->create();
$model->load($id);
$model->delete();
$this->messageManager->addSuccess(__('The post has been deleted.'));
return $resultRedirect->setPath('*/*/');
} catch (\Exception $e) {
$this->messageManager->addError($e->getMessage());
return $resultRedirect->setPath('*/*/index', ['id' => $id]);
}
}
$this->messageManager->addError(__('We can\'t find a post to delete.'));
return $resultRedirect->setPath('*/*/');
}
}
21) Then, For save the records in DB, create Save.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action;
use Magento\Backend\Model\Auth\Session;
class Save extends \Magento\Backend\App\Action
{
/**
* @var \Magento\Backend\Model\Auth\Session
*/
protected $_adminSession;
/**
* @var \Rh\Blog\Model\BlogFactory
*/
protected $blogFactory;
/**
* @param Action\Context $context
* @param \Magento\Backend\Model\Auth\Session $adminSession
* @param \Rh\Blog\Model\BlogFactory $blogFactory
*/
public function __construct(
Action\Context $context,
\Magento\Backend\Model\Auth\Session $adminSession,
\Rh\Blog\Model\BlogFactory $blogFactory
) {
parent::__construct($context);
$this->_adminSession = $adminSession;
$this->blogFactory = $blogFactory;
}
/**
* Save blog record action
*
* @return \Magento\Backend\Model\View\Result\Redirect
*/
public function execute()
{
$postObj = $this->getRequest()->getPostValue();
$name = $postObj["name"];
$date = date("Y-m-d");
$username = $this->_adminSession->getUser()->getFirstname();
if ($username == $name) {
$username = $this->_adminSession->getUser()->getFirstname();
} else {
$username = $name;
}
$userDetail = ["name" => $username, "created_at" => $date];
$data = array_merge($postObj, $userDetail);
$resultRedirect = $this->resultRedirectFactory->create();
if ($data) {
$model = $this->blogFactory->create();
$id = $this->getRequest()->getParam('id');
if ($id) {
$model->load($id);
}
$model->setData($data);
try {
$model->save();
$this->messageManager->addSuccess(__('The data has been saved.'));
$this->_adminSession->setFormData(false);
if ($this->getRequest()->getParam('back')) {
return $resultRedirect->setPath('blog/*/edit', ['id' => $model->getId(), '_current' => true]);
}
return $resultRedirect->setPath('*/*/');
} catch (\Magento\Framework\Exception\LocalizedException $e) {
$this->messageManager->addError($e->getMessage());
} catch (\RuntimeException $e) {
$this->messageManager->addError($e->getMessage());
} catch (\Exception $e) {
$this->messageManager->addException($e, __('Something went wrong while saving the data.'));
}
$this->_getSession()->setFormData($data);
return $resultRedirect->setPath('*/*/edit', ['id' => $this->getRequest()->getParam('id')]);
}
return $resultRedirect->setPath('*/*/');
}
}
22) After that, For mass delete records action, create MassDelete.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action\Context;
use Magento\Framework\Controller\ResultFactory;
use Magento\Ui\Component\MassAction\Filter;
use Rh\Blog\Model\ResourceModel\Blog\CollectionFactory;
/**
* Mass Delete Record Controller
*/
class MassDelete extends \Magento\Backend\App\Action
{
/**
* @var Filter
*/
protected $filter;
/**
* @var CollectionFactory
*/
protected $collectionFactory;
/**
* @param Context $context
* @param Filter $filter
* @param CollectionFactory $collectionFactory
*/
public function __construct(
Context $context,
Filter $filter,
CollectionFactory $collectionFactory
) {
$this->filter = $filter;
$this->collectionFactory = $collectionFactory;
parent::__construct($context);
}
/**
* @return \Magento\Backend\Model\View\Result\Redirect
*/
public function execute()
{
$deleteIds = $this->getRequest()->getPost('id');
$collection = $this->collectionFactory->create();
$collection->addFieldToFilter('id', ['in' => $deleteIds]);
$delete = 0;
foreach ($collection as $item) {
$item->delete();
$delete++;
}
$this->messageManager->addSuccess(__('A total of %1 record(s) have been deleted.', $delete));
$resultRedirect = $this->resultFactory->create(ResultFactory::TYPE_REDIRECT);
return $resultRedirect->setPath('*/*/');
}
}
23) Then, For mass status update action, create MassStatus.php file at app/code/Rh/Blog/Controller/Adminhtml/Grid/ and paste the below code :
<?php
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*/
/**
* Created By : Rohan Hapani
*/
namespace Rh\Blog\Controller\Adminhtml\Grid;
use Magento\Backend\App\Action\Context;
use Magento\Framework\Controller\ResultFactory;
use Magento\Ui\Component\MassAction\Filter;
use Rh\Blog\Model\ResourceModel\Blog\CollectionFactory;
/**
* Mass status update controller
*/
class MassStatus extends \Magento\Backend\App\Action
{
/**
* @var Filter
*/
protected $filter;
/**
* @var CollectionFactory
*/
protected $collectionFactory;
/**
* @param Context $context
* @param Filter $filter
* @param CollectionFactory $collectionFactory
*/
public function __construct(
Context $context,
Filter $filter,
CollectionFactory $collectionFactory
) {
$this->filter = $filter;
$this->collectionFactory = $collectionFactory;
parent::__construct($context);
}
/**
* Update product(s) status action
*
* @return \Magento\Backend\Model\View\Result\Redirect
*/
public function execute()
{
$ids = $this->getRequest()->getPost('id');
$status = $this->getRequest()->getPost('status');
$collection = $this->collectionFactory->create();
$collection->addFieldToFilter('id', ['in' => $ids]);
$updateStatus = 0;
try {
foreach ($collection as $item) {
$item->setStatus($status)->save();
$updateStatus++;
}
} catch (Exception $e) {
$this->messageManager->addExceptionMessage($e, __('Something went wrong while updating the product(s) status.'));
}
$this->messageManager->addSuccess(__('A total of %1 record(s) have been updated.', $updateStatus));
/** @var \Magento\Backend\Model\View\Result\Redirect $resultRedirect */
$resultRedirect = $this->resultFactory->create(ResultFactory::TYPE_REDIRECT);
return $resultRedirect->setPath('*/*/');
}
}
view folder
24) Then, For create layout of index page, create blog_grid_index.xml file at app/code/Rh/Blog/view/adminhtml/layout/ and paste the below code :
<?xml version="1.0"?>
<!--
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*
* Created By : Rohan Hapani
*/
-->
<page xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="../../../../../../../lib/internal/Magento/Framework/View/Layout/etc/page_configuration.xsd">
<body>
<referenceContainer name="content">
<block class="Rh\Blog\Block\Adminhtml\Grid" name="grid_grid_listing"/>
</referenceContainer>
</body>
</page>
25) After that, For create layout of edit page, create blog_grid_edit.xml file at app/code/Rh/Blog/view/adminhtml/layout/ and paste the below code :
<?xml version="1.0"?>
<!--
/**
* Copyright © Magento, Inc. All rights reserved.
* See COPYING.txt for license details.
*
* Created By : Rohan Hapani
*/
-->
<page xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" layout="admin-2columns-left" xsi:noNamespaceSchemaLocation="../../../../../../../lib/internal/Magento/Framework/View/Layout/etc/page_configuration.xsd">
<update handle="editor"/>
<body>
<referenceContainer name="content">
<block class="Rh\Blog\Block\Adminhtml\Grid\Edit" name="grid_grid_edit"/>
</referenceContainer>
<referenceContainer name="left">
<block class="Rh\Blog\Block\Adminhtml\Grid\Edit\Tabs" name="grid_grid_edit_tabs">
<block class="Rh\Blog\Block\Adminhtml\Grid\Edit\Tab\Main" name="grid_grid_edit_tab_main"/>
<action method="addTab">
<argument name="name" xsi:type="string">main_section</argument>
<argument name="block" xsi:type="string">grid_grid_edit_tab_main</argument>
</action>
</block>
</referenceContainer>
</body>
</page>
26) At the last, For grid column html content display, create view.phtml file at app/code/Rh/Blog/view/adminhtml/templates/grid/ and paste the below code :
<?php echo $block->getGridHtml(); ?>
Now, setup upgrade module and clean cache using below commands :
php bin/magento s:up
php bin/magento s:s:d -f
php bin/magento c:c
Output :
I hope this blog will helpful for easily understand about how to create admin grid and form without ui component. In case, I missed anything or need to add some information, always feel free to leave a comment in this blog, I’ll get back with proper solution
